Description

Diablo’s next generation saw blades for aluminum are optimized for cutting thin (up to 1/8 in), medium (3/32 in – 1/4 in) and thick (3/16 in – 7/16 in) aluminum metals. Featuring the new, specially formulated Diablo TiCo super-density micro-grain carbide, these radical blades withstand impact, reduce wear, provide clog free cuts and last longer than standard carbide in metal cutting applications. The specially formulated metal cutting carbide teeth feature a Triple Chip Grind (TCG) tooth design for clean, burr-free finishes, virtually eliminating any type of rework. Tri-metal shock resistant brazing allows these aluminum blades to slice through metal materials while withstanding extreme impact for maximum durability. Diablo’s Aluminum saw blade series is ideal for corded and cordless saws when on-the-job cutting non-ferrous metals such as aluminum extrusions, copper pipe, brass plate, etc.

Feature Bullets

• TiCo Super-Density micro-grain carbide for extreme cutting life and clog free cuts
• Tri-metal shock resistant brazing for extreme impact and maximum durability
• Triple Chip Grind (TCG) Tooth Geometry for maximum life, speed and durability, giving clean, burr-free cuts
• Laser-cut stabilizer vents for trapping noise and reducing vibration for accuracy and durability
• Perma-SHIELD Non-Stick Coating for protection against heat, gumming and corrosion

Specifications:

• Diameter: 12 in
• Arbor Hole Size: 5/8 in
• Maximum Speed Rating: 5000 rpm
• Blade Material: TiCo Hi-Density Carbide
• Cut Materials: Thick Aluminum, Plastics, Copper, Brass, Fiberglass
• Suitable For Use With: Miter Saw, Slide Miter Saw
• Number of Teeth: 72
• Teeth Style: TCG
• Kerf: 0.11 in
• Hook Angle: -5 deg
