Description

This Louisville 12 ft pinnacle platform step ladder has a 300 lb load capacity, rated ANSI Type IA. It features a 30 in extended handrail (perfect tool belt height) and a 30% larger platform area for added comfort and safety. This ladder is equipped with the innovative ProTop with multiple tool slots and magnet, SHOX impact absorption system, Raptor boots with non-marring bonded tread mechanically fastened to the upper boot to create a secure slip-resistant footing, wide back braces and double-rivet step construction. The Louisville FXP1710 pinnacle platform ladder meets or exceeds the safety standards set by ANSI and OSHA.

Feature Bullets

• 30 in Tall extended handrail from top to platform
• 30% Larger platform area for added comfort and safety
• ProTop with multiple tool slots and magnet
• Raptor slip-resistant boot
• Shox impact absorption system
• Double-rivet step construction
• Wide back braces

Specifications:

Duty Rating: Grade IA
Weight: 300 lb
Platform Material: Fiberglass
Platform Height: 12 ft
Platform Width: 14-1/2 in
Platform Depth: 17-5/8 in
Number of Steps: 10
Overall Height: 11.5 ft
Maximum Reach: 193 in
Open Volume: 28.81 cu-ft
Open Height: 167-1/2 in
Open Depth: 92 in
Open Width: 36.75 in
Closed Volume: 38.36 cu-ft
Closed Height: 176 in
Closed Depth: 10 in
Closed Width: 36.8 in
Top Width Closed: 18.43 in
Platform Front Width: 14-1/2 in
Platform Rear Width: 14-1/2 in
Platform Height: 1.218 in
