Feature Bullets

• AWS (Auto-Start Wireless System) uses Bluetooth technology to communicate between tool and vacuum and enable wireless control when used with Makita AWS cordless tools
• Brushless DC motor with high power to weight and size ratio
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing/production applications
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load condition, enabling rapid movement between high speed and high torque applications
• Battery protection system provides over-discharge, temperature and current protection for enhanced performance, battery cycle life and overall battery life
• High performance and lightweight design with magnesium diecast baseplate
• Constant speed control maintains constant speed under heavy load
• Overload protection prevents motor burnout due to current overload
• Depth stopper enables splinter free cutting
• VS dial enables operator to adjust cutting speed based on materials or application
• LED charge level indicator displays approximate remaining battery power
• Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
• Soft start feature gradually increases speed to eliminate start up shock
• Bevel capacity of -1o – 40 deg with positive stop at 22.5 deg and 45 deg
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Specifications:

Type: Brushless
Series: LXT
Bare Tool/Kit: Tool
Tool Type: Saw
Blade Diameter: 6-1/2 in
Blade Type: Plunge
Blade Material: Carbide Tipped
Cutting Depth: 2-3/16 in @ 0 deg, 1-9/16 in 45 deg, 1-1/2 in 48 deg
Arbor Hole Size: 13/16 in
Cutting Angle: 0 deg, 45 deg, 48 deg
Voltage Rating: 36 V
Speed Rating: 2500-6300 rpm
Sound Level: 92 dBA
Overall Length: 13-5/8 in
Vibration Level: 2.5 m/sq-s
Includes: B-57342 6-1/2 in 56T CT Blade, 783203-8 Hex Wrench, 197213-3 Interlocking Case
