Description

Water, dirt and impacts – tools have to take a lot. With the TECH 196 DL electronic spirit level, you are ideally equipped for hard days at the construction site. Cleaning under running water is no problem thanks to ULTRA-PROTECT and the high-precision electronic module does not need to be calibrated – even after falling or being exposed to temperature fluctuations. The innovative features of this German Made quality product simplify every measuring task: two digital displays with illumination, acoustic guidance and numerous display modes. State-of-the-art technology for productive work.

Feature Bullets

• Cal-free – Calibration of the electronic system is not necessary during daily use even if the product is dropped or following temperature fluctuations
• Ultra-Protect -: Optimum protection against dust and water as per IP 67 – the spirit level can temporarily be submerged in water
• Pitch Mode -: Defined 1/12, 2/12, 3/12 etc. Optimum readability: Two digital displays that can be illuminated at the touch of a button, Acoustic guidance: Align components quickly without having to look at the spirit level – with two di erent audible signals,
• Ref Node – Accept, save and transfer an angle measurement to other components
• Key-Lock – Keypad lock to protect against accidental inputs, Display modes: deg, %, mm/m, in/- decimal and as fraction, Long operating time: Up to 400 hours, Includes bag for safe transport, Magnetic Version with extra-strong rare-earth magnet system and two digital displays to instantly measure inclinations, slopes and angles
• Long operating time: Up to 400 hours
• Includes bag for safe transport
• Acoustic guidance with two different audible signals
• Two digital displays with optimal read-out in any application situation
• The digital display rotates to the reverse position

Specifications:

Type: Type 196
Power Supply: Battery
Display Type: Digital
Length: 9 in
Accuracy: +/-1/32 in @ 72 in
Number of Vials: 2
Housing Material: Aluminum
Battery Size: 2 AA
IP Rating: IP 67
Includes: Case
Country of Origin: Germany

Documents

Instruction/Installation Manual
Documents

Catalog
